| power | 12000  W  |
| voltage | 230/400  V  |
| heating circuits | 3    |
| mounting position | left    |
| L | 280  mm  |
| W | 225  mm  |
| H | 32  mm  |
| flange length | 45    |
| flange length 1 | 9,6    |
| flange length 2 | 35,4    |
| flange o1 | 44,5    |
| flange o2 | 39,5    |
| thermostat sleeves o | 7  mm  |
| length thermostat sleeves | 280  mm  |
| number of thermostat sleeves | 1    |
| position thermostat sleeves | eccentric, non clinging    |
| windings | 5    |
| L1 | 10  mm  |
| L2 | 270  mm  |
| W1 | 13  mm  |
| W2 | 31  mm  |
| tube o | 8,5  mm  |
| cable length | 600  mm  |
| mounting | turning flange    |
| application | fryer    |
| connection length | 50  mm  |
